The Rotator R-20-120

Description

The Rotator R-20 by Oxipack is an automated in-line leak detection system designed for flexible MAP-packages, enabling comprehensive control over both the process and quality of the production line. Capable of testing 20 to 120 packages per minute, it seamlessly integrates into the production line for efficient integrity checks. Its universal chambers allow for the simultaneous testing of various MAP packaging types.

In operation, packages are fed to the Rotator’s conveyor belt, then positioned by a shooting belt into the test chamber. This chamber, comprising a rigid bottom plate and a flexible top membrane, closes to create a vacuum for the leak test. Once tested, packages are sorted onto either reject or OK belts, ensuring only quality packages proceed in the production line. The Rotator R-20 in-line leak detection system stands out for its non-destructive, accurate testing and full integration into production lines, ensuring consistent product quality.

If you are not looking to test in-line, but still want to test multiple packs or sachets simultaneously, take a look at the Stationary Leak Tester XXXL (SLT XXXL) as a possible solution.
