PMB Moisture Analysers
With simple operation and rapid response time, PMB moisture analysers offer top value in their class. The automatic test-setting function enables easy recall for frequent testing of the same items without additional user programming. USB and RS-232 interfaces provide computer and printer connections to store test programs and results. No additional software is needed to take readings.
- Overview
- Features & Benefits
- Technical Specifications
- Physical Specifications
- Applications
- Resources
Description
Quick, easy moisture checks
- Straightforward operation for quick and accurate moisture checks
- Multiple heat settings available
- Fast sample heating in 1ºC increments with 400-watt halogen bulb
Built to last
- Durable housing protects internal components and holds up to daily use
- RS-232/USB outputs and optional printer for printing results
- Supplied with 5-year manufacturer’s warranty
Models
Choose from three models, with 50g, 160g and 200g capacities available. All models have a 100mmm diameter pan for samples.
Features & Benefits
- Three settings for heating sample include ramp-up, stepped temperatures and single temperature
- Four preset drying modes allow test routines for several products
- Testing can be set to start automatically when lid closes
- Quick and easy configuration using the keypad
- Internal memory stores 49 different recipes and up to 99 test results, while additional test results and settings can be stored on a flash drive
- Temperature range 50°C to 160°C in one-degree increments
- RS-232 interface provides speedy connection to computers and printers
- USB interface included for sending results to PC or recording on USB stick
- Pan lifter allows easy placement and removal of samples
- Scratch-resistant aluminum housing protects internal components
- Multilingual display allows use in many different countries
- Calibration for temperature and weight
- Audible overload alarm warns when capacity is exceeded
- Capacity tracker built into display for easily monitoring possible overloads
- Security slot for optional lock and cable to help prevent theft
- Vivid, backlit LCD easily visible in any lighting conditions
- Units of measurement displayed: g, %M, %S, ATRO %M, ATRO %S
Technical Specifications
Model Capacity Readability Pan Size
| PMB 53 | 50g | 0.001g/0.01% | 100mmø |
| PMB 163 | 160g | 0.001g/0.01% | 100mmø |
| PMB 202 | 200g | 0.01g/0.05% | 100mmø |
Physical Specifications
Physical Specifications
- 18.5 cm x 25 cm x 36 cm
- 6 kg
Power
- Power cord
Applications
- Moisture determination
- Weighing
Resources
