BYK-Gardner Micro-Gloss Meter
60° measurement is for semi-gloss paint and plastic – with the micro-gloss gloss meter you can measure any material – paints, plastics or highly reflective or mirror-like metals. All angles measure at the same location, and the results appear simultaneously – including Statistics, Difference, or Pass/Fail (ideal for QC and checks in the field)
Description
The micro-gloss has been the unsurpassed industry standard in gloss measurement for many years. It is the only gloss meter combining the highest accuracy,
ease-of-use and multiple functionality – essential for today’s testing requirements. In addition, the smart-chart software is the ideal tool for smart communication with professional documentation and efficient data analysis.
Features & Benefits
- Smart functions for any task
- Brilliant colour display: easy to read – easy to use
- Auto diagnosis: Standard OK – Calibration OK
- Gloss of paint or metal – from matte to mirror gloss
- See changes under the right angle
- Gloss and film thickness in one instrument
- Small port for small parts
Technical Specifications
SPECIFICATIONS:
Measurement range: 1 0 – 100 GU / 100 – 2000 GU
Repeatability: ±0.2 GU / ±0.2 %
Reproducibility: ±0.5 GU / ±0.5 %
Spectral sensitivity: CIE standard observer for illuminant CIE-C
Measuring time: 0.5 seconds / geometry
Thickness:
Substrate – Fe: magnetic, NFe: non-magnetic
Measurement Range: 0 – 500Mm (0 – 20 mils)
Accuracy: ±(1.5Mm +2% of measured value)
Memory: 999 readings with date and time
Interface: USB
Power supply: one 1.5V AA Alkaline Battery 4,000 readings or via USB-port
Comes complete with:
Glossmeter
Holder with integrated calibration tile
Traceable certificate
USB-cable, Battery
Operating manual
Carrying case
Software for download: smart-lab Gloss or smart-process Gloss with 2 licenses
Note: After software download, both software packages can be used for 30 day free trial. Thereafter, the user needs to decide and register for one software package.
Accessories
USB-Cable micro-gloss family – For data transfer from the glossmeter to a PC, USB-A
Software smart-lab Gloss – Software for professional analysis and documentation in the laboratory
Software smart-process Gloss – Process QC Software for analysis of multi-component products
