TMI 22-48-01 ECT Pneumatic Cutter
Rectangular punch for quick, precise and effective cutting of the samples used for ECT tests
Description
This pneumatic cutter is designed for quick, precise and effective cutting of the samples used for ECT tests. It is equipped with singe bevelled blades according to the Billerud standards
Technical Specifications
Specifications
- Model: 22-48-01
- Width: 25mm +/- 0.5mm
- Parallelism: +/- 0.1mm
- Max. Length: 145 mm
- Max. Thickness: 9mm
- Air Pressure: 8 bars
- No electricity needed
Maximum Height – The maximum sample heightis 9mm. The instrument is strong enough to cut through multiple layers of corrugated board
Plexiglas Protection – The Plexiglas protection cover makes safely working possible. Sliding in your sample is easy.
Change Blades – The single bevelled blade makes a perfect straight cut. Spare blades can be supplied in packages of 100 pieces.
